High-efficiency 430W bifacial solar panel with 22.0% module efficiency, N-TOPCon cells, dual-glass design, and military-grade durability. Ideal for BIPV, desert, coastal, and extreme environments. Maximize yield and reliability.
Features
- 24V off-grid solar panel.
- 14-busbar N-Type TOPCon cells with up to 25.1% efficiency.
- Excellent IAM and low-light performance for reliable energy production.
- Bifacial design delivers up to 25% additional rear-side power gain, depending on surface albedo.
- 108-cell configuration delivers a reliable 430W output.
- 2.0 mm front and rear tempered glass maximizes durability and bifacial performance.
- Power tolerance 0 to +5W ensures at least the rated output.
- Excellent low-light performance on cloudy days and at dawn/dusk.
- PID-resistant and 100% EL-inspected to help prevent microcracks.
- Rated for 5400 Pa snow loads and 2400 Pa wind loads.
- Certified to UL 61730, IEC 61215, and CSA C22.2 standards.
- Ideal for residential, agricultural, and commercial off-grid.
Installation
- Anodized aluminum frame – lightweight, strong, and corrosion-resistant
- 12 pre-drilled mounting holes for Z brackets, tilt mounts, pole, or ground installation
- MC4 connectors with 4 ft pre-attached cables for quick and easy installation
- Compatible with both on-grid and off-grid inverters
- 25-year output warranty.
- 10-year workmanship warranty.
What's included
- Panel Leads (Pair): 12 AWG, 4 ft each
- IP68-rated waterproof junction box
- IP67-rated waterproof solar connectors
- Peak Power: 430W
- Module Efficiency: 22.0%
- Max Power Voltage (Vmp): 31.9V
- Max Power Current (Imp): 13.5A
- Open Circuit Voltage (Voc): 37.4V
- Short Circuit Current (Isc): 14.7A
- Max Series Fuse Rating: 30A
- Maximum System Voltage: 1500VDC
- Number of Cells: 108 cells
- Front Glass: 2.0 + 2.0 mm Tempered Glass
- Frame Material: Anodized Aluminum Alloy
- Operating Temperature: -40°F to 185°F
- Dimensions : 67.8" × 44.7" × 1.2"
- Weight: 50.9 lb
Specifications
| Peak Power |
430W |
| Module Efficiency |
22.0% |
| Max Power Voltage (Vmp) |
31.9V |
| Max Power Current (Imp) |
13.5A |
| Open Circuit Voltage (Voc) |
37.4V |
| Short Circuit Current (Isc) |
14.7A |
| Max Series Fuse Rating |
30A |
| Maximum System Voltage |
1500VDC |
| Number of Cells |
108 cells |
| Front Glass |
2.0 + 2.0 mm Tempered Glass |
| Frame Material |
Anodized Aluminum Alloy |
Questions about this product, shipping, or warranty? Contact Tricky Lizard.
SKU: RS-M430BF-8
