Victron MultiPlus-II 12/4000/160-50 120V
SKU: PMP122405100
$1,105.00 $1,105.00 $1,300.00
Sale 15.0% $195.00 (15.0%)
Shipping calculated at checkout.
Out of stock
Description
Datasheet Dimension drawing Manual

New high-output 12V MultiPlus-II. 3400W continuous (4000VA), 160A charger, 50A transfer. Not the 12/3000, not the upcoming 2x120V 12/4000, not 230V.

  • 3400W continuous at 25°C / 4000W for 1h cold start / 6000W peak 2s
  • 160A adaptive charger
  • PowerControl / PowerAssist; dual AC outs; VE.Bus
  • Larger footprint than 12/3000 (639 × 277 × 164 mm)
DC input voltage range 9.5–17V
Output (inverter mode) 120 VAC ± 2%, 60 Hz
Continuous output power at 25°C 3400W (4000VA)
Continuous output power at 40°C 3100W
Time-limited power (cold start) 4000W / 1h; 4500W / 30 min
Peak power 6000W / 2s
Transfer switch 50A
Max battery charge current 160A
Max efficiency 93%
Zero-load power 18W (AES 11W / Search 4W)
Data / bus VE.Bus
Protection IP21
Weight 22 kg (48.5 lb)
Dimensions (h × w × d) 639 × 277 × 164 mm
SKU PMP122405100

You'll also need

The MultiPlus has no Bluetooth. Add a Cerbo GX MK2 and GX Touch 50, plus an RJ45 UTP cable between them. A SmartShunt 500 is the usual battery monitor.

Also available: the 12/4000 2x120V split-phase (PMP122405200). This listing is the single 120V model.

Questions: contact Tricky Lizard.
