Victron MultiPlus-II 12/4000/160-50 2x120V
SKU: PMP122405200
$1,190.00 $1,190.00 $1,400.00
Sale 15.0% $210.00 (15.0%)
Shipping calculated at checkout.
Out of stock
Description
Datasheet Dimension drawing Manual

New high-output 12V MultiPlus-II 2x120V for North American 50A 120/240V split-phase shore power. 3400W continuous (4000VA), 160A charger, 50A transfer per leg. Not the 12/3000 2x120, not the single 120V 12/4000.

  • 3400W continuous at 25°C / 4000W for 1h cold start / 6000W peak 2s
  • 160A adaptive charger
  • Pass-through both legs of 120/240V; in inverter mode L1+L2 share 120V (no 240V off battery)
  • PowerControl / PowerAssist; dual AC outs; VE.Bus
  • Larger footprint than 12/3000 2x120 (650 × 275 × 165 mm)
DC input voltage range 9.5–17V
Output (inverter mode) 120 VAC ± 2%, 60 Hz (L1 and L2 linked)
Shore / generator input 120/240V split-phase or single-phase 120V on L1
Continuous output power at 25°C 3400W (4000VA)
Continuous output power at 40°C 3100W
Time-limited power (cold start) 4000W / 1h; 4500W / 30 min
Peak power 6000W / 2s
Transfer switch 50A per leg
Max battery charge current 160A
Max efficiency 93%
Data / bus VE.Bus
Protection IP22
Weight 25 kg (55 lb)
Dimensions (h × w × d) 650 × 275 × 165 mm
SKU PMP122405200

You'll also need

The MultiPlus has no Bluetooth. Add a Cerbo GX MK2 and GX Touch 50, plus an RJ45 UTP cable between them. A SmartShunt 500 is the usual battery monitor.

Sold out until we source stock. This is the 2x120V split-phase model for 50A RV shore power. For single-phase 120V only, see the MultiPlus-II 12/4000 120V.

Questions: contact Tricky Lizard.
